SYN-SVKTINS16

M3 mounting frame

The fixing plate with M3 thread offers efficient and ease mounting of all D-sized chassis connectors by M3 screws.

Guide Pin

Guide pin to insert female contacts only. Remove the guide pin from the inserted contact and use it for the next contact.

Multipair SC-Quantum QMC; S-PVC; black, mat | 2 x 0,14 mm² x number of pairs | 12

Technical Data: - Properties: Strong PVC-jacket - Properties: OFC oxygen free copper - Properties: Digital 110 Ω AES / EBU - Properties: Analog - Properties: Torsion-free - Application area: Installation - Application area: Mobile outdoor / indoor - Application area: Stage / live - Application area: Studio / Broadcast - Application: Multipair - Colour: black - Colour detailed: black, mat - Signal transmission: symmetrical - Jacket material: S-PVC - Shielding: Copper spiral in pairs, tin-plated - UV-resistant: yes - Style variant: round - Packing: bulk stock

Heat shrink glue transparent

H-2(3X)
Thin-wall heat shrink tubing / flexible / flame retardant / 3:1

Features:
• Crosslinked Polyolefin
• Shrink ratio: 3:1
• Flame retardant
• General purpose
• High flexibility

Approvals:
• UL224 125 °C VW-1 600 V file E204071
• CSA file no.: 1934614
• Meets: RoHS, Sony-SS-00259

Application:
• Operating temperature: -55 °C to +125 °C
• Minimum shrink temperature: +70 °C
• Minimum full recovery temperature: +100 °C
• Longitudinal change: 0 ± 10% max.
Order information:

• Color: black
• Other colors: red, blue, yellow, green, white, transparent (flame retardant class 2)
