SCH-GT310-MFK

Easy-Lock 10E/16E/24E Black

Artikelnummer 09 00 000 5246 Beschrijving Han 10/16/24B Thermoplastic Lock. Lever Type sheet PDFPDF Identification Category Accessories Type of accessory Locking levers Locking type Single locking lever Version Size 10/16/24 B Material properties Material (accessories) Thermoplastic Colour (accessories) Black Net weight 18.74 g RoHS compliant

Declaration of Conformity

Insert Male 16E with screw contacts

Artikelnummer 09 33 016 2601 Beschrijving Han E MALE INSERT SCREW Type sheet PDFPDF Identification Category Inserts Series Han E® Termination method Screw termination Version Gender Male Size 16 B With wire protection Yes Number of contacts 16 PE contact Yes Technical characteristics Conductor cross-section 0.75 ... 2.5 mm² Electrical data acc. to IEC 61984 16 A 500 V 6 kV 3 Rated current 16 A Rated voltage 500 V Rated impulse voltage 6 kV Pollution degree 3 Rated voltage acc. to UL 600 V Rated voltage acc. to CSA 600 V Contact resistance ? 1 m? Limiting temperature -40 ... +125 °C Tightening torque 0.5 Nm Mating cycles ? 500 Material properties Material (insert) Polycarbonate Colour (insert) RAL 7032 (pebble grey) Net weight 85.8 g RoHS compliant with exemption Specifications and approvals Specifications IEC 61984 EN 60664-1 Approvals CSA-C22.2 No. 182.3 PVVA8.E318390 UL 1977 ECBT2.E235076 UL 2237 PVVA2.E318390 GL Yes

Declaration of Conformity

Adapter 3 pole XLR female - 3 pole XLR female

3 pole XLR female - 3 pole XLR female Gender conversion adapter Features & Benefits •Versatile, pre-wired and ready to use adapters to reliably interlock various connector systems •Professional look and compact space saving design, based on the XX Series •Rugged diecast shell for best reliability

Hood 16E/72DD - Top Entry - High - Levers - M32 - Black

Artikelnummer 19 30 716 0737 Beschrijving Han B Hood Coupler HC 2 Levers M32 Type sheet PDFPDF Identification Category Hoods/Housings Series of hoods/housings Han® B Type of hood/housing Cable to cable housing Description of hood/housing Black Type High construction Locking type Double locking lever Han-Easy Lock® Yes Version Size 16 B Version Top entry Cable gland 1x M32 Field of application Standard hoods/housings for industrial connectors Technical characteristics Limiting temperature -40 ... +125 °C Degree of protection acc. to IEC 60529 IP65 Degree of protection acc. to UL 50 12 4 4X Flammability acc. to UL 94 (locking levers) V-0 Material properties Material (hood/housing) Aluminium die-cast Surface (hood/housing) Powder-coated Colour (hood/housing) RAL 9005 (jet black) Material (seal) NBR Material (locking) Stainless steel Polycarbonate Colour (locking) RAL 7037 (dust grey) Net weight 264.8 g RoHS compliant Specifications and approvals GL Yes

Declaration of Conformity
